[Intelligent Scannin] Enjoy seamless tracking and frame stitching with POP 3’s 9-axis IMU (Inertial Measurement Unit). It continuously measures the scanner’s movement and helps to eliminate faulty frames caused by fast movement or shaking
[Time-Saving Accuracy] Achieve a single-frame precision of up to 0.05mm at up to 18fps for lightning-fast scans and reliable 3D model accuracy!
[Better Color Accuracy] Get improved color and texture accuracy through the RGB camera’s bigger aperture capturing more light and dual white LEDs providing supporting illumination to eliminate shadows and make the colors vibrant.
[Enhanced Marker Tracking] Capture scans using marker points faster and more reliably with dual infrared LEDs mounted next to both depth cameras providing extra light for better marker point tracking.
[More Control] Easily control your POP 3 with its three new touch-sensitive buttons that pause/start scanning and control the depth cameras' exposure.
Product Name |
POP 3 3D Scanner |
Output Formats |
PLY, OBJ, and STL |
Technology |
Dual Camera Infrared Light |
Point Distance/Resolution |
Minimum 0.05mm |
Single-frame Precision |
Up to 0.05mm |
Special Object Scanning |
Use scanning spray and the correct scanning mode for transparent, dark, or highly reflective objects. |
Single-frame Accuracy |
Up to 0.1mm |
Scanning Environment |
Indoors and Outdoors |
Single Capture Range |
225mm x 125mm |
Scanner Weight |
190g |
Working Distance |
150mm ~ 400mm |
Scanner Dimensions |
153mm x 29mm x 45mm |
Minimum Scan Volume |
20mm x 20mm x 20mm |
3D Printing Compatible |
Yes |
Scanning Speed |
12 - 18fps |
Compatible OS |
Window 10/11 (64-bit), Android, iOS, macOS |
IMU |
9-axis |
Auxiliary Lighting |
4 IR LEDs/ 2 White LEDs |
Light Source |
Class 1 Infrared Light |
Connection Modes |
Type-C USB 3.0 and Wi-Fi 6 |
Tracking Modes |
Feature/Marker |
External Controls |
3 Touch-sensitive buttons |
Color Scanning |
Yes |
|
|
1. Accuracy was acquired in a controlled lab environment. Actual results might vary, subject to the operation environment. 2. iOS devices only support Wi-Fi connection. 3. Revo Scan only supports model editing features in Windows and macOS. Models made on Android and iOS must be exported to a PC for editing. 4. Avoid direct sunlight when scanning outdoors. |
FAQ:
What are the differences between POP 2 and POP 3?
POP 3 has a 30% bigger RGM camera aperture and 2 white LEDs for better color scanning, an IMU for improved frame stitching, 4 infrared LEDs for improved marker tracking, faster scanning speeds (12 to 18fps), improved connectivity, and an easier-to-use design.
What’s special about POP 3’s IMU?
POP 3’s IMU is a 9-axis IMU with a gyroscope, accelerometer, and magnetometer that all work together to help POP 3 understands its location as you move the scanner around an object. This, in turn, helps POP 3 to provide smoother frame stitching as well as helping to eliminate any faulty frames captured caused by shaking or moving too fast.
What technology does the POP 3 use?
POP 3 uses class 1 infrared structured light, dual depth cameras, and advanced algorithms to output detailed 3D models.Do you need a powerful computer to use the POP 3?
No, the POP 3’s algorithms and internal chip do most of the processing.
Minimum specs: Intel i5, 8GB RAM.
Recommended specs: Intel i7, 16GB RAM.
No discrete GPU like an Nvidia or AMD graphics card is needed to use POP 3.
What devices are compatible with the POP 3?
The POP 3 can work with devices using:
Windows ≥ 10 (64-bit) can connect via USB or Wi-Fi
Android ≥ 9.0 (RAM≥6GB) can connect via USB or Wi-Fi
macOS ≥ Intel x86 chips 10.15 and M chips 11.0 can connect via USB or Wi-Fi
iOS ≥ 13.0 (iPhone 8 and onwards) iOS devices can only be connected via Wi-Fi
Does POP 3 have 3D scanning software?
Yes, the POP 3 comes with Revo Scan for free. It is compatible with iOS, macOS, Android, and Windows devices. In Revo Scan, you can perform scans and post-processing.
What formats can Revo Scan export?
Revo Scan can export your models in PLY, OBJ, and STL.
What are the Dual-axis Turntable’s specifications, and what comes in the box?
- Dual-axis Turntable Specifications:
Dimensions: (H) 82mm X (D) 200mm
Speed: 18 - 90 Seconds per Rotation
Max Load: 5kg
Product Gross Weight: 771g
Control Method: Via Revo Scan / APP
Rotation Control: Direction, Speed, and Start/Pause
Connection: Via Bluetooth
- What’s in the Box?
- Dual-axis Turntable
- Power Cable
- Multi-region Adapter (Supports US/EU/AU/GB plug types)
- Reusable Sticky Pad
- Attachable Table with Markers
